Description
ePA12
Developed based on PA12; low water absorption, the size of printed parts is less affected by humidity and temperature. ePA12 has high toughness, high impact resistance, and can be used to print durable parts; it has up to 165% elongation at break and excellent fatigue resistance; self-lubricating wear resistance, can print mechanical gears; high temperature resistance, thermal deformation The temperature is 100℃, can be used for temperature-resistant parts; low shrinkage, not easy to warp and crack during printing.
| Filament Properties Table | |
|---|---|
| 3D PRINTING FILAMENT | ePA12 |
| Density(g/cm3) | 1.012 |
| Heat Distortion Temp(℃,0.45MPa) | 100 |
| Melt Flow Index(g/10min) | 55.64(270℃/2.16kg) |
| Tensile Strength(MPa) | 50.81 |
| Elongation at Break(%) | 165.41 |
| Flexural Strength(MPa) | 47.27 |
| Flexural Modulus(MPa) | 659.49 |
| IZOD Impact Strength(kJ/㎡) | 10.14 |
| Durability | 10/10 |
| Printability | 8/10 |
| Recommended printing parameters | |
| Extruder Temperature(℃) | 260 – 290℃ Recommended temperature：280℃ |
| Bed temperature(℃) | 70 – 90°C |
| Fan Speed | 0% |
| Printing Speed | 40 – 100mm/s |
| Heated Bed | Required |
| Recommended Build Surfaces | Solid glue, PEI |
| Feature | |
| Flexible | √ |
| Elastic | —— |
| Impact Resistant | √ |
| Soft | —— |
| Composite | —— |
| UV Resistant | —— |
| Water Resistant | —— |
| Dissolvable | —— |
| Heat Resistant | √ |
| Chemically Resistant | —— |
| Fatigue Resistant | √ |
| Need drying | √ |
| Heated Bed Required | √ |
| Print recommend | Drying at 70℃/>12h |
Notes:
ePA12 needs to be dried (70℃/＞12H) before printing to achieve the best printing effect. It is recommended to use it with the eBOX cartridge when printing.
